.title[LP Examples: Generating Capacity Expansion] <br> .subtitle[BEE 4750/5750] <br> .subtitle[Environmental Systems Analysis, Fall 2022] <hr> .author[Vivek Srikrishnan] <br> .date[October 5, 2022]

---

# Outline

<hr>

1. Questions?
2. Using JuMP

---

# Poll

<hr>

URL: [https://pollev.com/vsrikrish](https://pollev.com/vsrikrish)

Text: **VSRIKRISH** to 22333, then message]

---

***Any questions?***

---

# Last Class

<hr>

* Coding Exercise with JuMP

---

# Overview of Electric Power Systems

<hr>

.center[![Structure of the Electric Power System](https://upload.wikimedia.org/wikipedia/commons/4/41/Electricity_grid_simple-_North_America.svg)]

---

# Power Systems Decision Problems

<hr>

.center[![Decision Problems for Power Systems](figures/elec-decision-problems.svg)] .center[.cite[Adapted from Perez-Arriaga, Ignacio J., Hugh Rudnick, and Michel Rivier (2009).]]

---

# Electricity Generation by Source

<hr>

.center[![U.S. Electricity Generation by Source, 2021](https://www.eia.gov/energyexplained/electricity/images/outlet-graph-large.jpg)]

---

# Capacity Expansion

<hr>

*Capacity expansion* involves adding resources to generate or transmit electricity to meet anticipated demand (load) in the future.

Typical objective is to minimize cost, but other constraints (such as reducing CO$_2$ emissions or increasing fuel diversity) may apply.

---

# Simple Capacity Expansion Example

<hr>

Let's look at a *very* simplified example first.

---

# Simple Capacity Expansion Example

<hr>

In general, we have many possible fuel options:

* Gas (combined cycle or simple cycle)
  * Coal
  * Nuclear
  * Renewables (wind, solar, hydro)

Each of these different types of plants has a different *capacity factor*, which reflects how much of the installed capacity can be relied upon at various times.

---

# Simple Capacity Expansion Example

<hr>

Assume we can simplify demand to two scenarios:

* On-peak: 3,760 hours with 3,000 MW of demand
  * Off-peak: 5,000 hours with 2,000 MW of demand

Generator types (only three):

| Tech  | Peak CF | Off-Peak CF | Investment Cost $(\\$\text{/MW-yr})$ | Operating Cost $(\\$\text{/MWh})$ |
|:-----:| -------:| -----------:| ------------------------------------:| ---------------------------------:|
|  Gas  |     0.9 |         0.9 |                              100,000 |                                50 |
| Wind  |     0.2 |         0.5 |                              150,000 |                                 0 |
| Solar |     0.7 |           0 |                              150,000 |                                 0 |

---

# Simple Capacity Expansion Example

<hr>

**Goal**: Find an installed capacity of each technology that meets demand at all periods at minimal *total cost*.

What are our variables?

| Variable  | Meaning                                               |
|:---------:|:----------------------------------------------------- |
|   $x_g$   | installed capacity (MW) of generator type $g$         |
| $y_{g,t}$ | production (MW) from generator type $g$ in period $t$ |

---

# Simple Capacity Expansion Example

<hr>

The objective function (to minimize cost):

$$
\begin{aligned}
\min\_{x\_g, y\_{g,t}} Z &= \color{red}\text{investment cost} + \color{blue}\text{operating cost} \\\\
&= \color{red}100000 x\_\text{gas} + 150000 x\_\text{wind} + 150000 x\_\text{solar} \\\\
& \color{blue}\quad + (3760 \times 50) y\_\text{gas,peak} + (5000 \times 50) y\_\text{gas,off}
\end{aligned}
$$

---

# Simple Capacity Expansion Example

<hr>

More generally (as the problem size gets larger), we want to write this more compactly.

If $C^{INV}_g$ is the investment cost for generator $g$, $C^{OP}_g$ is the operating cost for generator $g$, and $L_t$ is the length of time period $t$:

$$
\min Z = \sum\_g C^\text{INV}\_g x\_g + \sum\_g \sum\_t L\_t C^\text{OP}\_g y\_{g,t}
$$

---

# Simple Capacity Expansion Example

<hr>

What are the constraints?

* Generators cannot produce more than their installed capacity and availability, *e.g.*

$$
y\_\text{wind, peak} \leq 0.2 x\_\text{wind}
$$

* Need to serve load in both peak and off-peak hours:

$$
\begin{aligned}
y\_\text{gas, peak} + y\_\text{wind, peak} + y\_\text{solar, peak} &= 3000 \\\\
y\_\text{gas, off} + y\_\text{wind, off} + y\_\text{solar, off} &= 2000
\end{aligned}
$$

---

# Simple Capacity Expansion Example

<hr>

And don't forget non-negativity!

$$
\begin{aligned}
x\_g &\geq 0 \\\\
y\_{g,t} &\geq 0
\end{aligned}
$$

---

# Simple Capacity Expansion Example

<hr>

Notice that this is an LP!

* Linear (costs scale linearly);
  * Divisible (since we're modeling installed capacity, not number of individual units);
  * Certainty (no uncertainty about renewables)

Things can get more complex for real decisions, particularly with renewables...

---

# Simple Capacity Expansion Example

<hr>

```julia
using JuMP
using HiGHS

gencap = Model(HiGHS.Optimizer)
generators = ["gas", "wind", "solar"]
periods = ["peak", "off"]
G = 1:length(generators)
T = 1:length(periods)
@variable(gencap, x[G] >= 0)
@variable(gencap, y[G, T] >= 0)
@objective(gencap, Min, [100000; 150000; 150000]' * x
    + sum([188000 0 0; 250000 0 0]' .* y))
```

```
100000 x[1] + 150000 x[2] + 150000 x[3] + 188000 y[1,1] + 250000 y[1,2]
```

---

# Simple Capacity Expansion Example

<hr>

```julia
avail = [0.9 0.2 0.5; 0.9 0.5 0]' # availability factors
@constraint(gencap,
    availability[g in G, t in T], y[g, t] <= avail[g, t] * x[g]
)
```

```
2-dimensional DenseAxisArray{JuMP.ConstraintRef{JuMP.Model, MathOptInterface.ConstraintIndex{MathOptInterface.ScalarAffineFunction{Float64}, MathOptInterface.LessThan{Float64}}, JuMP.ScalarShape},2,...} with index sets:
    Dimension 1, 1:3
    Dimension 2, 1:2
And data, a 3×2 Matrix{JuMP.ConstraintRef{JuMP.Model, MathOptInterface.ConstraintIndex{MathOptInterface.ScalarAffineFunction{Float64}, MathOptInterface.LessThan{Float64}}, JuMP.ScalarShape}}:
 availability[1,1] : -0.9 x[1] + y[1,1] ≤ 0.0  …  availability[1,2] : -0.9 x[1] + y[1,2] ≤ 0.0
 availability[2,1] : -0.2 x[2] + y[2,1] ≤ 0.0     availability[2,2] : -0.5 x[2] + y[2,2] ≤ 0.0
 availability[3,1] : -0.5 x[3] + y[3,1] ≤ 0.0     availability[3,2] : y[3,2] ≤ 0.0
```

---

# Simple Capacity Expansion Example

<hr>

```julia
demand = [3000; 2000] # load
@constraint(gencap,
    load[t in T], sum(y[:, t]) == demand[t])
```

```
1-dimensional DenseAxisArray{JuMP.ConstraintRef{JuMP.Model, MathOptInterface.ConstraintIndex{MathOptInterface.ScalarAffineFunction{Float64}, MathOptInterface.EqualTo{Float64}}, JuMP.ScalarShape},1,...} with index sets:
    Dimension 1, 1:2
And data, a 2-element Vector{JuMP.ConstraintRef{JuMP.Model, MathOptInterface.ConstraintIndex{MathOptInterface.ScalarAffineFunction{Float64}, MathOptInterface.EqualTo{Float64}}, JuMP.ScalarShape}}:
 load[1] : y[1,1] + y[2,1] + y[3,1] = 3000.0
 load[2] : y[1,2] + y[2,2] + y[3,2] = 2000.0
```

---

# Simple Capacity Expansion Example

<hr>

```julia
print(gencap)
```

```
Min 100000 x[1] + 150000 x[2] + 150000 x[3] + 188000 y[1,1] + 250000 y[1,2]
Subject to
 load[1] : y[1,1] + y[2,1] + y[3,1] = 3000.0
 load[2] : y[1,2] + y[2,2] + y[3,2] = 2000.0
 availability[1,1] : -0.9 x[1] + y[1,1] ≤ 0.0
 availability[2,1] : -0.2 x[2] + y[2,1] ≤ 0.0
 availability[3,1] : -0.5 x[3] + y[3,1] ≤ 0.0
 availability[1,2] : -0.9 x[1] + y[1,2] ≤ 0.0
 availability[2,2] : -0.5 x[2] + y[2,2] ≤ 0.0
 availability[3,2] : y[3,2] ≤ 0.0
 x[1] ≥ 0.0
 x[2] ≥ 0.0
 x[3] ≥ 0.0
 y[1,1] ≥ 0.0
 y[2,1] ≥ 0.0
 y[3,1] ≥ 0.0
 y[1,2] ≥ 0.0
 y[2,2] ≥ 0.0
 y[3,2] ≥ 0.0
```

---

# Simple Capacity Expansion Example

<hr>

```julia
optimize!(gencap)
objective_value(gencap)
```

```
1.2580444444444444e9
```

---

# Simple Capacity Expansion Example

<hr>

```julia
value.(x)
```

```
1-dimensional DenseAxisArray{Float64,1,...} with index sets:
    Dimension 1, 1:3
And data, a 3-element Vector{Float64}:
 2444.4444444444443
 4000.0
   -0.0
```

---

# Simple Capacity Expansion Example

<hr>

```julia
value.(y)
```

```
2-dimensional DenseAxisArray{Float64,2,...} with index sets:
    Dimension 1, 1:3
    Dimension 2, 1:2
And data, a 3×2 Matrix{Float64}:
 2200.0     0.0
  800.0  2000.0
    0.0    -0.0
```

---

# Simple Capacity Expansion Example

<hr>

In summary:

* We want to install 2444.4 MW of gas, 4000 MW of wind, and no solar.
  * During peak hours, we rely on all of the gas and wind we can.
  * Off-peak, we rely on only wind.

**Does this solution make sense**?

---

# Simple Capacity Expansion Example

<hr>

How can we display these results more easily? Use `DataFrames.jl`:

```julia
using DataFrames

# compute total generation by generation resource
period_hours = [3760; 5000]
generation = [sum(value.(y).data[g, :] .* period_hours) for g in G]

results = DataFrame(
    "Resource" => generators,
    "Installed (MW)" => value.(x).data,
    "Generated (GWh)" => generation/1000
)
```

---

# Simple Capacity Expansion Example

<hr>

<div><div style = "float: left;"><span>3×3 DataFrame</span></div><div style = "clear: both;"></div></div><div class = "data-frame" style = "overflow-x: scroll;"><table class = "data-frame" style = "margin-bottom: 6px;"><thead><tr class = "header"><th class = "rowNumber" style = "font-weight: bold; text-align: right;">Row</th><th style = "text-align: left;">Resource</th><th style = "text-align: left;">Installed (MW)</th><th style = "text-align: left;">Generated (GWh)</th></tr><tr class = "subheader headerLastRow"><th class = "rowNumber" style = "font-weight: bold; text-align: right;"></th><th title = "String" style = "text-align: left;">String</th><th title = "Float64" style = "text-align: left;">Float64</th><th title = "Float64" style = "text-align: left;">Float64</th></tr></thead><tbody><tr><td class = "rowNumber" style = "font-weight: bold; text-align: right;">1</td><td style = "text-align: left;">gas</td><td style = "text-align: right;">2444.44</td><td style = "text-align: right;">8272.0</td></tr><tr><td class = "rowNumber" style = "font-weight: bold; text-align: right;">2</td><td style = "text-align: left;">wind</td><td style = "text-align: right;">4000.0</td><td style = "text-align: right;">13008.0</td></tr><tr><td class = "rowNumber" style = "font-weight: bold; text-align: right;">3</td><td style = "text-align: left;">solar</td><td style = "text-align: right;">-0.0</td><td style = "text-align: right;">0.0</td></tr></tbody></table></div>

---

# Simple Capacity Expansion Example

<hr>

```julia
shadow_price.(load)
```

```
1-dimensional DenseAxisArray{Float64,1,...} with index sets:
    Dimension 1, 1:2
And data, a 2-element Vector{Float64}:
 -299111.1111111111
 -180355.55555555556
```

---

# Simple Capacity Expansion Example

<hr>

```julia
shadow_price.(availability)
```

```
2-dimensional DenseAxisArray{Float64,2,...} with index sets:
    Dimension 1, 1:3
    Dimension 2, 1:2
And data, a 3×2 Matrix{Float64}:
      -1.11111e5   0.0
      -2.99111e5  -1.80356e5
 -300000.0        -1.80356e5
```

---

# Capacity Expansion

<hr>

**What modifications can we make to this setup?**

---

**What modifications can we make to our basic generation capacity example?**

---

# Capacity Expansion

<hr>

**What modifications can we make to this setup?**

* More hours (not just peak/off-peak)
  * More generator types
  * Add in non-served demand (usually penalized by a cost in the objective)
  * Emissions (CO$_2$ or air pollutant)
  * Plant retirements (if we have existing plants)
  * Dynamic fuel prices

---

# Emissions

<hr>

We could add in emissions as a constraint or try to minimize emissions (instead of cost).

**How would we do this?**

* Would need information on emissions per generated Wh.

---

# Non-Served Energy

<hr>

It could be that it's cheaper to not serve energy during some periods than to build additional capacity.

**How would we implement this?**

* Add non-served energy penalty ($NSECost \times NSE_t$) to objective;
  * Generated electricity plus non-served energy equal demand.

---

# Non-Served Energy

<hr>

New objective:

$$
\begin{aligned}
\min\_{x\_g, y\_{g,t}, nse\_t} Z &= \text{investment cost} + \text{operating cost} + \text{NSE cost}\\\\
&= 100000 x\_\text{gas} + 150000 x\_\text{wind} + 150000 x\_\text{solar} \\\\
& \quad + (3760 \times 50) y\_\text{gas,peak} + (5000 \times 50) y\_\text{gas,off} \\\\
& \quad + NSECost \times nse\_t
\end{aligned}
$$

---

# Non-Served Energy

<hr>

New load constraints:

$$
\begin{aligned}
y\_\text{gas, peak} + y\_\text{wind, peak} + y\_\text{solar, peak} + nse\_\text{peak}&= 3000 \\\\
y\_\text{gas, off} + y\_\text{wind, off} + y\_\text{solar, off} + nse\_\text{off} &= 2000
\end{aligned}
$$

---

# Next Class

<hr>

* Air Pollution Modeling Example or Economic Dispatch
