09 Using Jump

.title[Using JuMP For Optimization in Julia] <br> .subtitle[BEE 4750/5750] <br> .subtitle[Environmental Systems Analysis, Fall 2022] <hr> .author[Vivek Srikrishnan] <br> .date[September 28, 2022]

---

# Outline

<hr>

1. Questions?
2. Using JuMP

---

# Poll

<hr>

URL: [https://pollev.com/vsrikrish](https://pollev.com/vsrikrish)

Text: **VSRIKRISH** to 22333, then message]

---

***Any questions?***

---

# Last Class

<hr>

* Introduction to Optimization
  * Search Algorithms
  * Constrained Problems and Lagrange Multipliers
  * Linear Programs

---

# Solving Optimization Problems in Julia

<hr>

The key package is [`JuMP.jl`](https://jump.dev/JuMP.jl/stable/).

`JuMP` provides tools to solve various types of optimization problems.

The key advantage of `JuMP` is that it allows for specification of optimization problems in a very intuitive syntax.

---

# Using `JuMP.jl`

<hr>

Need to load `JuMP` and a *solver* package. Table of solvers available [here](https://jump.dev/JuMP.jl/stable/installation/#Supported-solvers).

Which solver you pick depends on:

* Type of problem (LP, etc)
  * License (we'll stick with non-commercial licenses)

```julia
using JuMP
using HiGHS
```

]

---

# Example: Pesticide Application

<hr>

Let's use a pesticide application LP example to illustrate how to use `JuMP`.

This is an example of a *resource allocation* problems.

---

# Pesticide Example

<hr>

A farmer has access to a pesticide which can be used on corn, soybeans, and wheat fields and costs $\$70/\text{ha-yr}$ to apply.

| Pesticide Application (kg/ha) | Soybean Yields (kg/ha) | Wheat Yields (kg/ha) | Corn Yields (kg/ha) |
|:-----------------------------:|:----------------------:|:--------------------:|:-------------------:|
|               0               |          2900          |         3500         |        5900         |
|               1               |          3800          |         4100         |        6700         |
|               2               |          4400          |         4200         |        7900         |

]

|   Crop   | Annual Production Costs ($/ha-yr) | Selling Prices ($/kg) |
|:--------:|:---------------------------------:|:---------------------:|
| Soybeans |                350                |         0.36          |
|  Wheat   |                280                |         0.27          |
|   Corn   |                390                |         0.22          |

]

---

# Pesticide Example

<hr>

Recently, environmental authorities have declared that the farmer's *average* application rate on corn, soybeans, and wheat cannot exceed 0.6 kg/ha, 0.8 kg/ha, and 0.7 kg/ha, respectively.

How should the farmer plant crops and apply pesticides to maximize profits over 130 total ha if demand for each crop is 250,000 kg?

---

# Pesticide Example

<hr>

Now, let's create our model with `JuMP`.

```julia
farm_model = Model(HiGHS.Optimizer)
```

```
A JuMP Model
Feasibility problem with:
Variables: 0
Model mode: AUTOMATIC
CachingOptimizer state: EMPTY_OPTIMIZER
Solver name: HiGHS
```

---

# Pesticide Example: Notation

<hr>

First, let's establish some notation.

---

***What are our decision variables?***

---

# Pesticide Example: Notation

<hr>

First, let's establish some notation.

**Decision Variables**:

| Variable | Meaning                                                  |
|:--------:|:-------------------------------------------------------- |
|  $S_j$   | ha planted with soybeans with pesticide rate $j=0, 1, 2$ |
|  $C_j$   | ha planted with corn with pesticide rate $j=0, 1, 2$     |
|  $W_j$   | ha planted with wheat with pesticide rate $j=0, 1, 2$.   |

---

# Pesticide Example: Notation

<hr>

To add these variables into our `JuMP` model, use `@variable`:

```julia
@variable(farm_model, S[1:3] >= 0) # soy
@variable(farm_model, W[1:3] >= 0) # wheat
@variable(farm_model, C[1:3] >= 0) # corn
```

```
3-element Vector{JuMP.VariableRef}:
 C[1]
 C[2]
 C[3]
```

---

# Pesticide Example: Formulate Objective

<hr>

Next, let's formulate the objective function with the goal of maximizing profits.

---

***What information is relevant for the objective?***

---

# Pesticide Example: Formulate Objective

<hr>

Next, let's formulate the objective function with the goal of maximizing profits.

**Take some time to work on this.**

---

---

# Pesticide Example: Formulate Objective

<hr>

**Key**: Compute profit for each hectare by crop and pesticide rate:

$$
Z = \sum_{\text{crop}, i} \left[\left(\text{yield} \times \text{selling price}\right) - \text{total cost}\right]
$$

After some algebra:

$$
\begin{aligned}
Z = & 694S_0 + 948S_1 + 1164S_2 \\\\
& + 665W_0+757W_1+784W_2 \\\\
& + 908C_0+1014C_1+1278C_2
\end{aligned}
$$

---

# Pesticide Example: Formulate Objective

<hr>

To put this objective into our `JuMP` model, use `@objective`:

```julia
@objective(farm_model, Max, 694S[1] + 948S[2] + 1164S[3] + 665W[1] + 757W[2] +
  784W[3] + 908C[1] + 1014C[2] + 1278C[3])
```

```
694 S[1] + 948 S[2] + 1164 S[3] + 665 W[1] + 757 W[2] + 784 W[3] + 908 C[1] + 1014 C[2] + 1278 C[3]
```

Another way to write this, using vector arithmetic:

```julia
@objective(farm_model, Max, [694; 948; 1164]' * S + [665; 757; 784]' *
  W + [908; 1014; 1278]' * C)
```

---

# Pesticide Example: Constraints

<hr>

What are our constraints?

---

***What information is relevant for constraints?***

---

# Pesticide Example: Constraints

<hr>

What are our constraints?

* **Land area**: total used farmland area cannot exceed 130 ha.
  * **Demand**: No reason to grow more than 250,000 kg of any single crop.
  * **Regulation**: Average pesticide rates cannot exceed limit for each crop.
  * **Non-negativit**y**: No land allocation can be less than 0.

---

# Pesticide Example: Constraints

<hr>

---

Let's develop these constraints and put them into `JuMP`.

---

## Land Area

$$
S_0 + S_1 + S_2 + W_0 + W_1 + W_2 + C_0 + C_1 + C_2 \leq 130
$$

```julia
@constraint(farm_model, area, sum(S) + sum(W) + sum(C) <= 130)
```

```
area : S[1] + S[2] + S[3] + W[1] + W[2] + W[3] + C[1] + C[2] + C[3] ≤ 130.0
```

---

## Demand

$$
2900S_0 + 3800S_1 + 4400S_2   \leq 250000
$$

$$
3500W_0 + 4100W_1 + 4200W_2 \leq 250000
$$

$$
5900C_0 + 6700C_1 + 7900C_2 \leq 250000
$$

```julia
@constraint(farm_model, soy_demand, [2900; 3800; 4400]' * S <= 250000)
@constraint(farm_model, wheat_demand, [3500; 4100; 4200]' * W <= 250000)
@constraint(farm_model, corn_demand, [5900; 6700; 7900]' * C <= 250000)
```

```
corn_demand : 5900 C[1] + 6700 C[2] + 7900 C[3] ≤ 250000.0
```

---

## Regulatory Limits

$$
\frac{S_1 + 2S_2}{S_0+S_1+S_2} \leq 0.8
$$

But these need to be linear! So:

$$
S_1 + 2S_2 \leq 0.8(S_0 + S_1 + S_2) \Rightarrow -0.8 S_0 + 0.2 S_1 + 1.2S_2 \leq 0
$$

---

Similarly,

$$
\begin{aligned}
& W_1 + 2W_2 \leq 0.7(W_0 + W_1 + W_2) \\\\
& \Rightarrow -0.7 W_0 + 0.3 W_1 + 1.3 W_2 \leq 0
\end{aligned}
$$

$$
C_1 + 2C_2 \leq 0.6(C_0 + C_1 + C_2) \Rightarrow -0.6 C_0 + 0.4 C_1 + 1.4 C_2 \leq 0
$$

```julia
@constraint(farm_model, soy_pesticide, [-0.8; 0.2; 1.2]' * S <= 0)
@constraint(farm_model, wheat_pesticide, [-0.7; 0.3; 1.3]' * W <= 0)
@constraint(farm_model, corn_pesticide, [-0.6; 0.4; 1.4]' * C <= 0)
```

```
corn_pesticide : -0.6 C[1] + 0.4 C[2] + 1.4 C[3] ≤ 0.0
```

---

## Non-Negativity

We actually imposed the non-negativity constraints

$$
S_i, W_i, C_i >= 0
$$

when we defined the variables!

---

# Final Model: Printing

```julia
print(farm_model)
```

```
Max 694 S[1] + 948 S[2] + 1164 S[3] + 665 W[1] + 757 W[2] + 784 W[3] + 908 C[1] + 1014 C[2] + 1278 C[3]
Subject to
 area : S[1] + S[2] + S[3] + W[1] + W[2] + W[3] + C[1] + C[2] + C[3] ≤ 130.0
 soy_demand : 2900 S[1] + 3800 S[2] + 4400 S[3] ≤ 250000.0
 wheat_demand : 3500 W[1] + 4100 W[2] + 4200 W[3] ≤ 250000.0
 corn_demand : 5900 C[1] + 6700 C[2] + 7900 C[3] ≤ 250000.0
 soy_pesticide : -0.8 S[1] + 0.2 S[2] + 1.2 S[3] ≤ 0.0
 wheat_pesticide : -0.7 W[1] + 0.3 W[2] + 1.3 W[3] ≤ 0.0
 corn_pesticide : -0.6 C[1] + 0.4 C[2] + 1.4 C[3] ≤ 0.0
 S[1] ≥ 0.0
 S[2] ≥ 0.0
 S[3] ≥ 0.0
 W[1] ≥ 0.0
 W[2] ≥ 0.0
 W[3] ≥ 0.0
 C[1] ≥ 0.0
 C[2] ≥ 0.0
 C[3] ≥ 0.0
```

---

# Final Model: LaTeX

<hr>

```julia
latex_formulation(farm_model)
```

```
$$ \begin{aligned}
\max\quad & 694 S_{1} + 948 S_{2} + 1164 S_{3} + 665 W_{1} + 757 W_{2} + 784 W_{3} + 908 C_{1} + 1014 C_{2} + 1278 C_{3}\\
\text{Subject to} \quad & S_{1} + S_{2} + S_{3} + W_{1} + W_{2} + W_{3} + C_{1} + C_{2} + C_{3} \leq 130.0\\
 & 2900 S_{1} + 3800 S_{2} + 4400 S_{3} \leq 250000.0\\
 & 3500 W_{1} + 4100 W_{2} + 4200 W_{3} \leq 250000.0\\
 & 5900 C_{1} + 6700 C_{2} + 7900 C_{3} \leq 250000.0\\
 & -0.8 S_{1} + 0.2 S_{2} + 1.2 S_{3} \leq 0.0\\
 & -0.7 W_{1} + 0.3 W_{2} + 1.3 W_{3} \leq 0.0\\
 & -0.6 C_{1} + 0.4 C_{2} + 1.4 C_{3} \leq 0.0\\
 & S_{1} \geq 0.0\\
 & S_{2} \geq 0.0\\
 & S_{3} \geq 0.0\\
 & W_{1} \geq 0.0\\
 & W_{2} \geq 0.0\\
 & W_{3} \geq 0.0\\
 & C_{1} \geq 0.0\\
 & C_{2} \geq 0.0\\
 & C_{3} \geq 0.0\\
\end{aligned} $$
```

---

# Let's Solve!

<hr>

To solve, run `optimize!()`.

```julia
optimize!(farm_model)
```

```
Running HiGHS 1.3.0 [date: 1970-01-01, git hash: e5004072b-dirty]
Copyright (c) 2022 ERGO-Code under MIT licence terms
Presolving model
7 rows, 9 cols, 27 nonzeros
7 rows, 9 cols, 27 nonzeros
Presolve : Reductions: rows 7(-0); columns 9(-0); elements 27(-0) - Not reduced
Problem not reduced by presolve: solving the LP
Using EKK dual simplex solver - serial
  Iteration        Objective     Infeasibilities num(sum)
          0    -1.8498422490e+02 Ph1: 7(28.3601); Du: 9(184.984) 0s
          8     1.1754885933e+05 Pr: 0(0) 0s
Model   status      : Optimal
Simplex   iterations: 8
Objective value     :  1.1754885933e+05
HiGHS run time      :          0.00
```

---

# Exploring the Solution

<hr>

```julia
solution_summary(farm_model)
```

```
* Solver : HiGHS

* Status
  Termination status : OPTIMAL
  Primal status      : FEASIBLE_POINT
  Dual status        : FEASIBLE_POINT
  Message from the solver:
  "kHighsModelStatusOptimal"

* Candidate solution
  Objective value      : 1.17549e+05
  Objective bound      : 1.17549e+05
  Relative gap         : Inf
  Dual objective value : 1.17549e+05

* Work counters
  Solve time (sec)   : 5.00106e-03
  Simplex iterations : 8
  Barrier iterations : 0
  Node count         : -1

```

---

# Exploring the Solution

<hr>

To get the optimal objective value, use `objective_value()`.

```julia
objective_value(farm_model)
```

```
117548.85932851679
```

---

# Exploring the Solution

<hr>

Optimal variable values can be accessed with `value()`.

```julia
value.(S)
```

```
3-element Vector{Float64}:
 13.812154696132593
 55.24861878453038
  0.0
```

`value()` is broadcasted over `S` above because `S` is a vector of variables.

---

# Exploring the Solution

<hr>

```julia
value.(C)
```

```
3-element Vector{Float64}:
 26.923076923076927
  0.0
 11.538461538461554
```

---

# Exploring the Solution

<hr>

```julia
value.(W)
```

```
3-element Vector{Float64}:
  6.743306417339565
 15.73438164045898
  0.0
```

---

# Exploring the Solution

<hr>

So, to optimize profits, the farmer should allocate land accordingly:

| Pesticide Application (kg/ha) | Soybean Area (ha) | Wheat Area (ha) | Corn Area (ha) |
|:-----------------------------:| -----------------:| ---------------:| --------------:|
|               0               |              13.9 |            26.9 |            6.7 |
|               1               |              55.2 |               0 |           15.7 |
|               2               |                 0 |            11.5 |              0 |

This will result in a profit of $117,549.

---

# Binding Constraints

<hr>

Recall that the solution will be found at one of the corner points of the feasible polytope.

This means that one or more constraint is **binding**: if we *relaxed* the constraint, we could improve the solution.

---

# Shadow Prices

<hr>

The *marginal cost* of the constraints, or the rate at which the solution could improve if the constraint capacity was relaxed by one unit, is captured by the *shadow price*.

Non-zero shadow prices tell us that the constraint is binding.

The value tells us which is most impactful on a per-unit basis.

---

# Shadow Prices

<hr>

The shadow prices are the *dual variables* of the constraints. We can access those with `shadow_price()` when they exist (which we can check with `has_duals()`).

```julia
has_duals(farm_model)
```

```
true
```

---

# Shadow Prices

<hr>

```julia
shadow_price(soy_pesticide)
```

```
212.2817679558011
```

```julia
shadow_price(corn_pesticide)
```

```
140.44615384615383
```

```julia
shadow_price(wheat_pesticide)
```

```
92.0
```

---

# Shadow Prices

<hr>

```julia
shadow_price(soy_demand)
```

```
0.046353591160221023
```

```julia
shadow_price(wheat_demand)
```

```
-0.0
```

```julia
shadow_price(corn_demand)
```

```
0.044553846153846166
```

---

# Shadow Prices

<hr>

```julia
shadow_price(area)
```

```
729.4
```

---

# Shadow Prices

<hr>

What can we learn from this analysis?

* The farmer is meeting demand for soy and corn, but not wheat.
  * All of the pesticide constraints are binding.
  * The farmer is using all possible farmland (binding area constraint).
  * The most valuable change would be to increase land ($729/ha), then increasing the soy and corn pesticide limits.
  * The demand shadow prices look small, but think about scale (they're still the least impactful)!

---

# Shadow Prices and Lagrange Multipliers

<hr>

Where do shadow prices come from? They are the Lagrange Multipliers!

If our inequality constraints $X \geq A$ and $X \leq B$ are written as $X - S_1^2 = A$  and $X + S_2^2 = B$:

$$
H(X, S_1, S_2, \lambda_1, \lambda_2) = Z(X) - \lambda_1(X - S_1^2 - A) - \lambda_2(X + S_2^2 - B)
$$

and

$$
\frac{\partial H}{\partial A }= \lambda_1 \text{ and } \frac{\partial H}{\partial B} = \lambda_2.
$$

---

# A `JuMP` tip

<hr>

`JuMP` is great, because it lets us construct models with a very intuitive syntax.

However,`JuMP` does not like it when you try to redefine variables and constraints by overwriting ones that already exist with `@variable` and `@constraint`. For example:

```julia
@constraint(farm_model, area, sum(S) + sum(W) + sum(C) <= 150)
```

would return an error.

---

# Updating Models

<hr>

Instead, if you need to redefine a model, you can create a new model, `delete()` the relevant component, or use the modification commands, such as:

* [`set_normalized_coefficient`](https://jump.dev/JuMP.jl/stable/reference/constraints/#JuMP.set_normalized_coefficient): change a variable coefficient in a constraint
  * [`set_normalized_rhs`](https://jump.dev/JuMP.jl/stable/reference/constraints/#JuMP.set_normalized_rhs): change constraint capacity
  * [`set_lower_bound`](https://jump.dev/JuMP.jl/stable/reference/variables/#JuMP.set_lower_bound): change variable lower bound
  * [`set_upper_bound`](https://jump.dev/JuMP.jl/stable/reference/variables/#JuMP.set_upper_bound): change variable upper bound

As always, make sure to look at the documentation!

---

<hr>

# Next Class

<hr>

* Hands-on example with `JuMP`.
  * Bring laptop, and `git pull` the class examples repository!
